G90 Industrial Vehicle 4G CAT6 LTE Router
  • HOMTECS/OEM
  • CHINA
  • 3 DAYS FOR SAMPLES
  • 10000PCS/MONTH

4 Gigabit Ethernets,4 LAN or 3 LAN + 1 WAN
VPN (PPTP/L2TP, IPSec, GRE, OpenVPN)
RS232/RS485 optional
5G/4G/3G/2G
WiFi 2.4G+5G optional
GPS/Beidou optional
Dual SIM optional
Cloud management optional

G90 Industrial Vehicle 4G CAT6 LTE Router

Industrial Vehicle 4G LTE Router

Overview:

G90 Industrial Vehicle 4G CAT6 LTE Router is a kind of internet of things wireless communication router, use FDD/TDD-LTE 4G mobile broadband network type to provide convenient and high speed net transmission function.


G90 Industrial Vehicle 4G CAT6 LTE Router uses high performance industrial ARM Dual-Core communication processor, flush bonding real-time operation system as software supporting platform, provide save, high speed, stable 4G wireless router net. G90 Industrial Vehicle 4G CAT6 LTE Router is a wireless router with 4 Gigabit Ethernet ports, 3 GPIO and 1 USB, provides 2.4G WiFi + 5G WiFi.


G90 Industrial Vehicle 4G CAT6 LTE Router can be used in ATM, POS, Vending, Kiosk, finance, postal, smart power grids, smart transportation, environment monitor, fire protection monitor, security, water conservancy, public safety, advertising release, industrial control, earth quake monitor, meteorological watch, instrument monitor.etc


Application

 CAT6 LTE Router

Vehicle 4G LTE Router


Features:

Industrial robust design and compact metal housing

Strong electromagnetic interference Resistance, heat endurance and radiation ability

Support FDD/TDD-LTE 4G network, 3G and 2.5G backward compatible

Support multiple VPN (PPTP, L2TP, GPE, IPSec etc.)

Support multiple network protocol (ICMP, TCP, UDP, Telnet, SSH, HTTP, HTTPS etc.)

Support multiple functions (DHCP, DNS, DDNS, Firewall, NAT, DMZ host etc.)

2 Antenna interfaces, 1 GSM+ 1 Aux/Wi-Fi/GPS

4 Ethernets, 4 LAN or 3 LAN + 1 WAN

WAN port support PPPoE, static IP, DHCP client.

Built-in watch dog, Multi-link detection ensure working in stable and security way

Always online, reboot automatically if disconnected to ensure continual connection

Support APN and VPDN wireless private network access in

LCP/ICMP/flow/heartbeat check, ensure network usability

Web/CLI/SSH/Management platform support, easy configure

SNMP network management, NTP support

Local & remote management (configuration, status, upgrade firmware)

Supports Port forwarding and Bridge

Supports timing operation

Supports LED status indication

Shock and vibration resistant



Advanced:

MIMO Antenna for LTE 300Mbps optional

802.11b/g/n, ac Wi-Fi optional, 2.4G + 5G WiFi optional

Dual-redundancy between WAN links: Ethernet, 3G/4G and Wi-Fi backup

GPS capability optional for fleet management or other tracking application

DTU serial communication function optional (rs232/rs485)

OpenVPN Optional

PPTP Sever optional

AT command optional

Control by SMS optional

Schedule reboot optional

Customized and OEM/ODM acceptable



Specification

Cellular


4G(FDD LTE/TDD LTE)



AU: B1/B3/B5/B7/B8/B28, B40
EU: B1/B3/B7/B8/B20/B28/B31, B38/B40
US: B2/B4/B5/B13/B17/B25, B41
JP: B1/B3/B8/B9/B18/B19/B21/B28, B41
CN: B1/B3, B38/B39/B40/B41

3G(UMTS/WCDMA/HSDPA/HSUPA/HSPA+)



850/900/1900/2100 MHz

850/1900/2100 MHz

900/2100 MHz

2G(EDGE/GPRS/CDMA/EVDO)

850/900/1800/1900 MHz



Antenna Interface


Number of ports

1 or 2 (MAIN + AUX/WiFi/GPS)

SIM

1 or 2(3 V & 1.8 V)

Ethernet Interface


Number of ports

4 x 10/100/1000 Mbps, 4 LAN or 3 LAN + 1 WAN

Magnet isolation protection

1.5 KV

Serial Interface


Number of ports

3 GPIO(2 RS-232 or 1 RS232 + 1 RS-485)

Baud rate

300bps to 230400bps

Software


VPN tunnel

PPTP/L2TP, IPsec, GRE, OpenVPN

Firewall

DMZ, NAT, Filtering (IP/MAC/Port/Url/Access/Domain name)

Management

Web, CLI/Telnet Command, M2M management platform optional, SSH optional, SMS optional

Serial port

Transparent, TCP Client/Server, UDP, Modbus RTU

Others


Reset button

1 x RST

LED indicators

1 x PWR, 1 x 2.4G WLAN, 1 x 5G WLAN, 1 x NET, 4 x LAN, 1 x SYS

Power

5 to 32 V DC(standard 12V/1.5A)

Power consumption

Idle: 240 mA@12 V

Data link: 500 mA (peak) @12 V

Housing & Weight

Metal(IP34), 600 g

Dimension

180 x 127 x 54 mm

Installation

Desktop, wall mounting and DIN rail mounting

Certification

CE, RoHs, FCC



Model reference:

Homtecs

G90 Series Industrial Cellular Router

Model

4G

3G

DL

UL

Interface

SIM

WiFi

GPS

G90-FA2T

FDD/TDD LTE

UMTS

150Mbps

50Mbps

4XLAN

3XGPIO

2



G90-FA2T-W

FDD/TDD LTE

UMTS

150Mbps

50Mbps

4XLAN

3XGPIO

2

Y


G90-FA2T-G

FDD/TDD LTE

UMTS

150Mbps

50Mbps

4XLAN

3XGPIO

2


Y

G90-FA2T-GW

FDD/TDD LTE

UMTS

150Mbps

50Mbps

4XLAN

3XGPIO

2

Y

Y

G90-FA4T

FDD/TDD LTE

UMTS

150Mbps

50Mbps

4XLAN

3XGPIO

2



G90-FA4T-W

FDD/TDD LTE

UMTS

150Mbps

50Mbps

4XLAN

3XGPIO

2

Y


G90-FA4T-G

FDD/TDD LTE

UMTS

150Mbps

50Mbps

4XLAN

3XGPIO

2


Y

G90-FA4T-GW

FDD/TDD LTE

UMTS

150Mbps

50Mbps

4XLAN

3XGPIO

2

Y

Y

G90-WA2T


HSPA+

21Mbps

5.76Mbps

4XLAN

3XGPIO

2



G90-WA2T-W


HSPA+

21Mbps

5.76Mbps

4XLAN

3XGPIO

2

Y


G90-WA2T-G


HSPA+

21Mbps

5.76Mbps

4XLAN

3XGPIO

2


Y

G90-WA2T-GW


HSPA+

21Mbps

5.76Mbps

4XLAN

3XGPIO

2

Y

Y

G90-WA4T


HSPA+

21Mbps

5.76Mbps

4XLAN

3XGPIO

2



G90-WA4T-W


HSPA+

21Mbps

5.76Mbps

4XLAN

3XGPIO

2

Y


G90-WA4T-G


HSPA+

21Mbps

5.76Mbps

4XLAN

3XGPIO

2


Y

G90-WA4T-GW


HSPA+

21Mbps

5.76Mbps

4XLAN

3XGPIO

2

Y

Y
